Definition of event triggers
Options
Channel x
Event trigger
Select Rx
Rx Enable
No Yes
Source item
[1] [1] [1]
Sound speed Flow/analysis Totalizers Fluid properties Diagnostic values Miscellaneous
Function
→ MAX (x>limit)
→ MIN (x<limit)
→ Within range
→ Out of range
→ ERR (x=fail)
Type
Non-hold Hold for a while Hold
Hold interval
Options
[2]
Channel x
→ Within range
→ Out of range
→ MAX
→ MIN
→ ERR
Outputs
Select output Range center Trigger value
Enable ... Range width Hysteresis
Yes
Glitch interval
Source item
Failure delay
→ Event trigger
Output range
Idle state
Output info
Legend
[1] not available for calculation channels
[2] depending on the selected function
Test signal
1
2
