Annex
PIOX S72* A Menu structure
215
UMPIOX_S72xV1-9EN, 2022-05-15
Example 2
The storage rate of all measured and diagnostic values of a certain temperature range is to be changed.
The normal storage rate of all measured and diagnostic values is 1 h. If the temperature is outside the defined range of 20...40 °C,
the storage rate should be 1 min. At the same time a record has to be carried out 10 s before and 60 s after the event.
The temperature range of 0...100 °C has to be determined via a current input of 4...20 mA.
Trigger:
Condition:
Action:
20 °C > fluid temperature > 40 °C on current input I1
I1 as trigger value outside the range 20...40 °C
store measured values within the temperature range 20...40 °C with a storage rate of 1 h
Special functions Special functions
Inputs Data logger
Current I1 Configuration
Enable I1 Logger channels
Yes Start storing
→ Event-based
→ With input
Source item
→ Temperature
Storage rate
I1 Input range → 1 h
→ 4…20 mA
Storage rate (trig.)
Start of meas. range → 1 min
→ 0.0 °C
Buffer time →П
End of meas. range → 10 s
→ 100.0 °C
Buffer time П→
Error value → 60 s
→ Yes
→ 3.50 mA
Ringbuffer
Trigger value Storage mode
Yes Store totalizers
Function Store diagnost. values
→ Out of range
Store transd. temp.
Range center
→ 30.0 °C
Range width
→ 20.0 °C
Glitch interval
→ 1 s
Input info
Test signal
Test mea. range
