Figure 18.7 Josef Stefan (1835–1893), and Ludwig Boltzmann (1844–1906)
Using the Stefan-Boltzmann formula to calculate the power radiated by the human
body, at a temperature of 300 K and an external surface area of approx. 2 m
2
, we
obtain 1 kW. This power loss could not be sustained if it were not for the compen-
sating absorption of radiation from surrounding surfaces, at room temperatures
which do not vary too drastically from the temperature of the body – or, of course,
the addition of clothing.
18.3.4 Non-blackbody emitters
So far, only blackbody radiators and blackbody radiation have been discussed.
However, real objects almost never comply with these laws over an extended
wavelength region – although they may approach the blackbody behavior in
certain spectral intervals. For example, a certain type of white paint may appear
perfectly white in the visible light spectrum, but becomes distinctly gray at about
2 μm, and beyond 3 μm it is almost black.
There are three processes which can occur that prevent a real object from acting
like a blackbody: a fraction of the incident radiation α may be absorbed, a fraction
ρ may be reflected, and a fraction τ may be transmitted. Since all of these factors
are more or less wavelength dependent, the subscript λ is used to imply the
spectral dependence of their definitions. Thus:
■
The spectral absorptance α
λ
= the ratio of the spectral radiant power absorbed
by an object to that incident upon it.
■
The spectral reflectance ρ
λ
= the ratio of the spectral radiant power reflected
by an object to that incident upon it.
■
The spectral transmittance τ
λ
= the ratio of the spectral radiant power transmit-
ted through an object to that incident upon it.
The sum of these three factors must always add up to the whole at any wavelength,
so we have the relation:
18.3 – Blackbody radiation
Publ. No. 1 557 536 Rev. a35 – ENGLISH (EN) – January 20, 2004 93
