8.2 Keypad buttons & functions
Figure 8.4 Camera buttons – explanations
CommentsButton
■ Press briefly to switch on the camera
■ Press and hold down for a few seconds to switch off the cam-
era
ON/OFF
■ Press briefly to autoadjust the camera
■ Press and hold down for a few seconds autofocus the camera
A
■ Press briefly to freeze an image
■ Press briefly to store an image if the image is currently frozen
■ Press and hold down for a few seconds to store without
freezing the image
■ Press to move between panes in some dialog boxes
■ Press to leave freeze mode and go to live mode
S
■ Press to leave dialog boxes without changing any settings
■ Press twice to leave edit mode
■ If the camera is in manual adjust mode, press to change the
function of the joystick to level (up/down) and span (left/right)
C
■ Press to display the menu system
■ Press to exit the menu system
■ Press to confirm selections and leave dialog boxes
■ Press to select the spot
■ Move up/down or left/right to navigate in menus, dialog
boxes, and on the screen
■ Move up/down to change focus and left/right to zoom
■ If the camera is in manual adjust mode, press C to change the
function of the joystick to level (up/down) and span (left/right)
Joystick
Press + or – to focus
+/–
Press to autoadjust
F1
Press to autofocus
F2
8.3 Autofocus
To focus the camera using the autofocus feature, press and hold down the A
button for one second.
NOTE: Please note the following:
■ The area that the camera uses when autofocusing is a 80 × 60 pixel box, centered vertically and
horizontally on the screen
■ The camera will have difficulties autofocusing when the image has low contrasts between different
areas
■ You should keep the camera steady when autofocusing
36 Publ. No. 1 557 536 Rev. a35 – ENGLISH (EN) – January 20, 2004
8.2 – Keypad buttons & functions
