11 A note on LEMO connectors
11.1 How to connect & disconnect LEMO connectors
The male LEMO connectors used on the camera cables are designed to lock se-
curely to the female connectors on the camera body. A connector consists of a
fixed inner tube and a sliding outer tube. The outer tube controls the locking
teeth. To unlock the connector, pull the outer tube in the indicated direction. See
the figure below
NOTE: Never pull the cable.
10062403;2
Figure 11.1 Straight body LEMO connector.
DescriptionCallout
Locking teeth
1
Sliding outer tube
2
Fixed inner tube
3
Publ. No. 1 557 536 Rev. a35 – ENGLISH (EN) – January 20, 2004 59
