10.2 External battery charging
10345803;3
Figure 10.1 Stand-alone battery charger
The battery status while charging is indicated by a number of LEDs. See the figure
below.
10346203;4
Figure 10.2 LED indicators on the stand-alone battery charger.
Figure 10.3 LED indicators – explanations
Color & modeIndicator #Situation
Fixed red light1The charger is under power,
but no battery is inserted
Fixed green light1The charger is under power,
and a battery is inserted
Flashing green light1The battery is too cold or too
warm
56 Publ. No. 1 557 536 Rev. a35 – ENGLISH (EN) – January 20, 2004
