The temperature scale is displayed on the right-hand side of the screen. The scale
shows how the colors are distributed along the various temperatures in the image,
with high temperatures at the upper end and low temperatures at the lower end.
9.1.4 System messages
9.1.4.1 Status messages
Status messages are displayed at the bottom of the screen, or in the top left part
of the screen. Here you will find information about the current status of the camera,
etc.
Figure 9.4 Status messages – a few examples
ExplanationMessage
Message is displayed when the image is frozen.
Frozen
Message is displayed when the camera is currently in manual
adjust mode.
Manual
Message is displayed when the software is restarted, i.e. after
Factory default.
Restarting
Message is displayed while an image is being saved.
Saving as
9.1.4.2 Warning messages
Warning messages are displayed in the center of the screen. Here you will find
important information about battery status, etc.
Figure 9.5 Critical camera information – a few examples
ExplanationMessage
The battery level is below a critical level.
Battery low
The camera will be switched off immediately.
Shutting down
The camera will be switched off in 2 seconds.
Shutting down in 2 seconds
9.2 Menu system
9.2.1 Navigating in the menu system
■
Press the joystick to display the horizontal menu bar
■
Press the joystick to confirm selections in menus and dialog boxes
■
Press the C button to exit the menu system
■
Press the C button to cancel selections in menus and dialog boxes
■
Move the joystick up/down to move up/down in menus, submenus and dialog
boxes
40 Publ. No. 1 557 536 Rev. a35 – ENGLISH (EN) – January 20, 2004
9.2 – Menu system
