DTX Series CableAnalyzer
Technical Reference Handbook
7-14
Fiber Test Settings
Table 7-2 describes the test settings that apply to fiber
cabling.
To access the fiber test settings turn the rotary switch to
SETUP; then select Fiber. Use BC to see different tabs.
Table 7-2. Fiber Test Settings
Setting Description
SETUP > Fiber >
Fiber Type
Select a fiber type that is appropriate for the type you will test. Selecting Custom lets you create a
fiber type. See page 11-2 for details.
SETUP > Fiber >
Test Limit
Select the appropriate test limit for the job. The tester compares the fiber test results to the
selected test limit to produce PASS or FAIL results. Selecting Custom lets you create a test limit. See
page 11-4 for details.
SETUP > Fiber >
Remote End Setup
Use Smart Remote mode for testing dual-fiber cabling.
Use Loopback mode for testing reference test cords, patch cords, and cable spools.
Use Far End Source mode with an optical source for testing individual fibers.
SETUP > Fiber >
Bi-Directional
When enabled in Smart Remote or Loopback mode, the tester prompts you to swap the test
connections halfway through the test. The tester can then make bi-directional measurements for
each fiber at each wavelength (850 nm/1300 nm, 850 nm/1310 nm, or 1310 nm/1550 nm).
