Getting Acquainted
Basic Features
1-21
1
Verifying Operation
The tester performs a basic self test when you turn it on. To
run a more thorough self test for an acceptance test or as
part of a routine equipment check:
1
Connect the main and remote testers as shown in
Figure 1-9.
2
Turn the rotary switch to SPECIAL FUNCTIONS.
3
Use D to highlight Self Test; then press H.
4
If a fiber module is installed, select Mainframe.
5
Press P.
If the tester reports an error, refer to “If Something Seems
Wrong” on page 13-7.
amd41f.eps
Figure 1-9. Self Test Connections
Permanent link
adapter
Channel
adapter
TEST
LOW BATTERY
TONE
TALK
FAIL
TEST
PASS
TALK
TALK
MONITOR
ENTER
TEST
SAVE
SPECIAL
FUNCTIONS
SETUP
AUTO
TEST
SINGLE
TEST
EXIT
F1 F2
F3
