Fluke DTX-MFM2 Technical Reference Handbook

DTX Series CableAnalyzer
Technical Reference Handbook
3-12
PASS*/FAIL* Results
A result marked with an asterisk means that measurements
are in the tester’s accuracy uncertainty range (Figure 3-7)
and the “*” notation is required by the selected test
standard. These results are considered marginal. Marginal
passing and failing results are marked with blue and red
asterisks, respectively.
A PASS* may be considered a passing result.
A FAIL* should be considered a failure.
amd42f.eps
Figure 3-7. PASS* and FAIL* Results
Limi
t
PASS*
PASS
*
FAIL
*
Tester's
accuracy
uncertainty
range
FAIL
FAIL*
PASS
