DTX Series CableAnalyzer
Technical Reference Handbook
13-28
DTX-COAX Coaxial Adapter Specifications
Input connector Male F-connector. BNC adapter allows connection to coaxial network cabling
Cable types tested Coaxial video and network cabling
Length Range: 800 m (2625 ft) with or without remote
Resolution: 0.1 m or 1 ft
Accuracy: 0 m to 150 m (0 ft to 492 ft): ±(0.3 m + 2 %)
150 m to 800 m (492 ft to 2625 ft): ±(0.3 m + 4 %)
Propagation delay Range: 4000 ns with or without remote
Resolution: 1 ns
Accuracy: 0 ns to 750 ns: ±(2 ns + 2%); 750 ns to 4000 ns: ±(2 ns + 4%)
Loop resistance Range: 0 Ω to 530 Ω
Resolution: 0.1 Ω
Accuracy: ±(1 Ω + 1 %)
