Yellow LED to indicate that the digital
sensor is connected on the PAN side.
Digital sensor power supply on PAN side.
Yellow LED to indicate that the digital
sensor is connected on the CEPH side.
Digital sensor control signals on PAN side.
Orange LED. It follows the trigger signal
during the exam, blinks 1 second the rest
of time. Off during firmware update.
Green LED to indicate when the digital
sensor is powered.
Digital sensor power supply on CEPH side
(via CEPH interconnection board).
Red LED to indicate that the digital sensor
is READY to acquire images (computer
READY signal received).
Digital sensor control signal on CEPH side
(via CEPH interconnection board).
Panoramic Mode Signal from T point on
Power Switching board.
Control signals from and to the
microprocessor control board.
Switch for firmware update.
Power input from power board
(24V and 38V).
Connector for firmware update
(normally free).
Connected to Control Unit.
