FONA XPan DG Plus
97
2.3.2. Metal covers (Shields)
1
Shield on Power Supply Unit
Phillips screw, 2 on top
2
Shield on Power Switching
Phillips screw, 4 on sides
3
Back shield on Control Unit
Phillips screw, 4
