Check list of optional box temporal resting bar (optional)
1. Gear box with temporal bars
2. Mounting bolt (set of 2)
3. Resting bar tips (set of 4)
Check list of motorized column box (229x31x33cm - 42kg)
1. Motorized column
2. Bolts and washers for wall support
(set of two 8x20 with split washers)
3. Bolts and spacers for carriage holding PLATE
(set of 4 8x30)
4. Wall support
Check list of optional self-standing base (96x70x28cm - 38kg)
1. Self-standing base
2. Plastic cover
3. Mounting bolt 10x25 (set of 6)
4. Levelling screw (set of 4)
