11.22 Built-in Option Card Types and Ports in Which They Can be Installed
11-98
Other related function codes
Other related function codes that can be set with CANopen communication are shown in the following table.
Table 11.22-13
Function
code
Function code name
Factory
default
Data setting range
Description
o27
Operation when CANopen
communication error
detected
0
0 to 15
o28
Timer when CANopen
communication error
detected
0
0 to 60.0 s
o40 to
o43
*2
Applicable function code
setting written via RPDO
No.3
0x0000
0x0000 to
0xFFFF
Set the function code as follows:
0xXX■■
XX: Group (see table below)
■■: Number
Example) F07 → 0x0407
o48 to
o51
*2
Applicable function code
setting monitored via TPDO
No.3
0x0000
0x0000 to
0xFFFF
As above
y96
G1, GX1 compatibility
mode
0
0/2/3
0: Disable (factory default)
1: Reserved (cannot be set)
2: Enable (G1 compatible)
3: Enable (GX1 compatible)
y98
Run, frequency command
source selection
0
0 to 3
Select from the following.
Table 11.22-14
y98
Frequency
command
source
Run
command
source
0
Inverter
Inverter
1
CANopen
Inverter
2
Inverter
CANopen
3
CANopen
CANopen
*2 To reflect settings after setting o40 to o43 and o48 to o51, either turn the inverter unit power OFF and ON again,
or send a ResetNode command from the CANopen master.
