Fujitsu ETERNUS CS800 - Page 55

Figure 17: Entry System with 8 Gb/s Fibre Channel
Figure 18: Entry System with 8 Gb/s Fibre Channel and with 10 Gb/s Ethernet
Variants Slots
1 2 3 4 5 7
no option internal
RAID
controller
- Riser
card
4 x 1 Gb/s
Ethernet
- external
RAID
controller
with 10 Gb/s
Ethernet option
internal
RAID
controller
- Riser
card
4 x 1 Gb/s
Ethernet
2 x 10 Gb/s
Ethernet
external
RAID
controller
with 8 Gb/s
Fibre Channel
option
internal
RAID
controller
2 x 8 Gb/s
Fibre Channel
Riser
card
4 x 1 Gb/s
Ethernet
- external
RAID
controller
with 10 Gb/s
Ethernet and
with 8 Gb/s
Fibre Channel
option
internal
RAID
controller
2 x 8 Gb/s
Fibre Channel
Riser
card
4 x 1 Gb/s
Ethernet
2 x 10 Gb/s
Ethernet
external
RAID
controller
Table 5: Usage of PCI Slots - Entry System, with JX40 S2 option
ETERNUS CS800 55
3 Hardware Description
