Fujitsu ETERNUS CS800 - ETERNUS DX100 S3 Expansion Modules - Rear View

LED name LED status Description
IDENTIFY
LED
blinks blue The installation location of the drive enclosure is identified
according to the instruction that is issued from ETERNUS Web
GUI or ETERNUS CLI.
Table 14: Status and Meanings of Each LED
3.2.6 ETERNUS DX100 S3 Expansion Modules - Rear View
This chapter describes the rear view of ETERNUS DX100 S3 storage expansion modules,
which includes connectors and indicators.
Figure 42: Rear view of DX100 S3 drive enclosure
Figure 43: Rear view of DX100 S3 - I/O module
ETERNUS CS800 71
3 Hardware Description
