Chapter 1 Scanner Overview
25
Index
Appendix
Introduction
Glossary
Contents
TOP
Loading
Documents
Scan
Parameters
Various
Documents
Daily Care
Trouble-
shooting
Operational
Settings
Consumables
Scanner
Overview
The Document Cover with a black document holding pad is optionally available. This type is convenient for scanning documents in black
background when loading them from the flatbed.
This option allows you to correct skewed document images after scanned with the flatbed and to recognize the size of document to
output at it original size.
Name: Black Document Pad
Parts No.: PA03338-D960
Document Bed
Place documents on the glass when
scanning through the flatbed.
Document Holding Pad
Holds documents to the Document Bed.
Document Cover
Holds the loaded documents at the scanning
position when closed.
ADF Lock Screw
Fixes the ADF.
Lock Screw Storage Hole
Stores the ADF Lock Screws that were
removed after the ADF has been
unlocked.
Handle
Used to open and close the Document
Cover.
