FIGURE 8-1 shows the locations of the PCIe slots.
FIGURE 8-1 PCIe Slot Locations
Location Number Component
1 PCIe slot (PCIe#0)
2 PCIe slot (PCIe#1)
3 PCIe slot (PCIe#2)
4 PCIe slot (PCIe#3)
4
3
2
1
