Fujitsu SPARC Enterprise M3000

9-2 SPARC Enterprise M3000 Server Service Manual • March 2012
FIGURE 9-1 shows the locations of the hard disk drives.
FIGURE 9-1 Hard Disk Drive Location
Location Number Component
1 Hard disk drive (HDD#0)
2 Hard disk drive (HDD#1)
3 Hard disk drive (HDD#2)
4 Hard disk drive (HDD#3)
2
1
3
4
