10-4 SPARC Enterprise M3000 Server Service Manual • March 2012
2. Remove the two cables from the rear of the hard disk drive backplane (2 in
FIGURE 10-2).
FIGURE 10-2 Removing the Cables of the Hard Disk Drive Backplane
3. Remove the cables connected to the CD-RW/DVD-RW drive unit.
For details, see Section 11.3, “Removing the CD-RW/DVD-RW Drive Unit” on
page 11-5.
4. Pull the CD-RW/DVD-RW drive unit out by several centimeters.
For details, see Section 11.3, “Removing the CD-RW/DVD-RW Drive Unit” on
page 11-5.
1
2
1
2
