12-4
SPARC Enterprise M3000 Server Service Manual
•
March 2012
4.
While pressing the lever (3 in
FIGURE
12-2
), pull
the handle outward (4 in
FIGURE
12-2
).
FIGURE
12-2
Removing the Power Supply Unit
5.
W
ith one hand suppor
ting the bottom of
the
power supply
, remove the power
supply unit.
6.
Place the power supply unit on a conductive mat.
2
3
Handle
Le
ver
Cord clamp
1
4
Po
w
e
r
c
o
r
d
143
