Fujitsu SPARC Enterprise M3000 Service Manual

2-2 SPARC Enterprise M3000 Server Service Manual • March 2012
FIGURE 2-1, FIGURE 2-2 and FIGURE 2-3 are the internal view, front view, and rear view
of the server, respectively, and they indicate the names and abbreviated names of
main components.
FIGURE 2-1 Server (Internal View)
Note – The form of the DC-DC converter may be different depending on the
motherboard unit which is mounted.
CPU
CD-RW/DVD-RW drive unit (DVDU)
Fan
unit
(FAN_A)
Memory (DIMM) XSCF unit (XSCFU)
PCIe
slot
Power supply unit (PSU)
DC-DC
converter
(DDC)
Fan backplane (FANBP_B)
PCIe card (PCIe)
Hard disk drive backplane
(HDDBP)
Motherboard unit

Fujitsu SPARC Enterprise M3000 Specifications

General

Brand	Fujitsu
Model	SPARC Enterprise M3000
Category	Server
Language	English
