5-2 SPARC Enterprise M3000 Server Service Manual • March 2012
Caution – To ensure that you and bystanders are not exposed to harm and to
prevent damage to the system, observe the ESD safety precautions. See Section 1.1,
“ESD Precautions” on page 1-1.
1. If the equipment rack is supplied with a Quake-Resistant Options Kit or
stabilizer, be sure to install it.
2. Slide the server out as far as possible.
When the server is drawn out completely, the server is automatically locked in
the predetermined position.
3. Loosen the two screws at the front of the server (
FIGURE 5-1).
FIGURE 5-1 Pulling the Server Out from an Equipment Rack
4. Slide the server out.
To Next Page
