2-182 SPARC Enterprise Mx000 Servers XSCF User’s Guide • January 2012
Note – Supported firmware releases and Oracle Solaris releases vary based on
processor type. For details, see the Product Notes that apply to the XCP release
running on your server and the latest version of the Product Notes (no earlier than
XCP version 1100).
The first firmware to support the newer M3000 server is the XCP 1080 firmware. For
specific information about minimum OS requirements, see the Product Notes for
your server.
FIGURE 2-9 shows an example of a mixed configuration of SPARC64 VI and SPARC64
VII processors.
FIGURE 2-9 CPUs on CPU/Memory Board Unit (CMU) and Domain Configuration
Example
Different types of processors can be mounted on a single CMU, as shown in CMU#2
and CMU#3 in
FIGURE 2-9. And a single domain can be configured with different
types of processors, as shown in Domain 2 in
FIGURE 2-9.
A domain runs in one of the following CPU operational modes:
