Chapter 2 Setting Up XSCF 2-29
Configuring XSCF Routing
In a redundant XSCF unit configuration, the following are examples of data when
routing is done in each subnet.
<Example>
Note – The method of determining the routing for an XSCF interface depends on
the network environment at the installation site. The network environment for
system operation must have a suitable configuration.
Note – You cannot set the routing to the takeover IP address.
â– Command operation
1. Use the showroute(8) command to display the routing environment.
XSCF Unit 0 XSCF Unit 1
xscf#0-lan#0 [192.168.1.10] xscf#1-lan#0 [192.168.1.20]
+------------------------------+
XSCF-LAN#0 XSCF-LAN#0
XSCF Unit 0 XSCF Unit 1
xscf#0-lan#1 [10.12.108.10] xscf#1-lan#1 [10.12.108.20]
+------------------------------+
XSCF-LAN#1 XSCF-LAN#1
Destination Gateway Netmask Interface
[192.168.1.0] - [255.255.255.0] xscf#0-lan#0
[default] [192.168.1.1] [0.0.0.0] xscf#0-lan#0
[192.168.1.0] - [255.255.255.0] xscf#1-lan#0
[default] [192.168.1.1] [0.0.0.0] xscf#1-lan#0
[10.12.108.0] - [255.255.255.0] xscf#0-lan#1
[default] [10.12.108.1] [0.0.0.0] xscf#0-lan#1
[10.12.108.0] - [255.255.255.0] xscf#1-lan#1
[default] [10.12.108.1] [0.0.0.0] xscf#1-lan#1
XSCF> showroute -a
Destination Gateway Netmask Flags Interface
10.12.108.0 * 255.255.255.0 U xscf#0-lan#0
default 10.12.108.1 0.0.0.0 UG xscf#0-lan#0
:
To Next Page
