GPSMAP
®
700 Series Owner’s Manual 43
Almanac, On-boat, and Environmental Data
Customizing Engine Gauge and Fuel Gauge Limits
To establish the upper and lower limits of a gauge, and the range of desired standard operation, you
can congure up to four values for the engine gauge or the fuel gauge. When a value exceeds the
range of standard operation, the gauge face or bar becomes red.
Setting Description
Scale minimum This value is less than the rated minimum, and it represents the lower limit of the gauge.
This setting is not available on all gauges.
Scale maximum This value is greater than the rated maximum, and it represents the upper limit of the
gauge. This setting is not available on all gauges.
Rated minimum Represents the minimum value of the standard operating range.
Rated maximum Represents the maximum value of the standard operating range.
1. From the Home screen, select Information > Dashboard Gauges > Engine > Menu > Gauge
Setup > Set Gauge Limits.
2. Select a gauge.
3. Select
Gauge Limits > Custom > Edit Limits.
4.
Select the gauge limit you want to set (Scale Min, Scale Max, Rated Min, or Rated Max).
NOTE: Some of these options may not be available for all gauges.
5. Select the gauge limit.
6. Repeat steps 4 and 5 to set additional gauge limits.
Activating Status Alarms for Engine Gauges and Fuel Gauges
If you have activated gauge status alarms, when the engine sends a warning status message over the
NMEA 2000 network, a gauge status alarm message appears. The gauge face or bar may become red
depending on the alarm type.
From the Home screen, select Information > Dashboard Gauges > Engine > Menu > Gauge
Setup > Status Alarms > On.
Customizing Engine and Fuel Gauge Status Alarms
1. From the Home screen, select Information > Dashboard Gauges > Engine > Menu > Gauge
Setup > Status Alarms > Custom.
2. Select one or more engine gauge or fuel gauge alarms that you want to turn on or off.
3. Select
Back.
Selecting the Number of Engines Shown in Gauges
The engine gauges can show information for up to four engines.
1. From the Home screen, select
Information > Dashboard Gauges > Engine > Menu > Gauge
Setup > Engine Selection > Number of Engines.
2. Select the number of engines.
3. Complete an action:
Select Back.
Select Edit Engines and complete steps 2 through 5 of “Selecting the Engines Shown in
Gauges” (page 44) to select the engines for which information appears in the gauges.
•
•
