13.2 Modem

The Gatewing modem (2.4 GHz) consists of the following parts:

E USB port

F Serial port

GOn/Off button

H Keyboard lock

I Camera activation

Entry Part

Entry Part

A Modem

B USB connector

C Modem antenna
