Gatewing X100UAS - 3.8 Check the wingtips

2.0 — 36 — 12 October 2012
X100 parts
Check the wingtips
4 Blow into the tube to check if nothing is blocking it.
3.8 Check the wingtips
P REREQUISITES
● Screwdriver torx T10
The wingtips must be firmly attached to the X100 body to prevent roll stability problems (wingtip
vortices).
1 Make sure the wingtips are intact.
2 Make sure each wingtip is firmly attached with two screws to the X100 body.
