2.0 — 34 — 12 October 2012

X100 parts

Download cable

3.5 Download cable

The download cable is used to download the log files from the X100 to the GCS. It consists of

the following parts:

3.6 Check the X100 body

REREQUISITES

● Soft brush and water

● Repairing materials prescribed by Gatewing

Entry Part

A Serial connector

B X100 connector
