11.1.1 Launch slide parts
The launch slide for the X100 consists of the following parts:
E Launch slide
F V-support with lock pin
G Support fix with two support fix pins
Entry Part
Entry Part
A Release handles
B Crank connector
C Launch hook
D Handles
E Launch cable
F Launch handle
