12.4 Battery charger parts

The Graupner Ultramat 14 plus charger consists of the following parts:

12.5 Power on the battery charger

REREQUISITES

● Battery charger

● 12 V car battery or a 100-240 VAC power supply

Entry Part

A Display

B Charger cable for X100

C Balancer connector

DEnter/Start button

E Car battery cable

F Power supply cable
