Gatewing X100UAS - 3.4.4 Pitot bay parts

2.0 — 31 — 12 October 2012
X100 parts
X100 body parts
3.4.4 Pitot bay parts
The pitot bay of the X100 body consists of the following parts:
Cover the pitot tube
P REREQUISITES
● X100 body
● Pitot cover
The pitot tube needs to be covered when:
● The X100 is in its case
● The X100 is on the dock, before the airspeed is being reset
Entry Part
A Pitot clamp
B Pitot tube
C Pitot cover
