2.0 — 104 — 12 October 2012
Tracker
F22 transmitter specifications
14.2 F22 transmitter specifications
The F22 transmitter has the following specifications:
Entry Part
A F22 transmitter
B R1 receiver
C On/off button
DScan button
E Increase/decrease gain buttons
F Four folding antennas
G Screen
HMENU/OK and Navigation buttons
I Earphone connector
Specification Value
Range Ground 15-28 km
3-4 m AGL 28-50 km
Mountain tops 50-80 km
Power 1/3N battery with a 7-day life
N
OTE: Low battery is indicated with two beeps
every three seconds. Replace the batteries to
ensure maximum transmitting power.
Weight 8.1 g
Frequency 433 MHz
