2.0 — 99 — 12 October 2012

GROUND CONTROL STATION

13.1 Ground control station (GCS)

The Trimble tablet PC ground control station consists of the following parts:

Entry Part

A Cursor

BEnter button

C Touchscreen

D Stylus
