Prepare for flight
Checks and preparations
2 Check if the elevons are moving up and down regarding the roll position
Pitch down Both elevons will go up
Roll left The left elevon will go up,
the right elevon will go
down.
Roll right The left elevon will go
down, the right elevon will
go up.
Position Figure Position elevons
