7 Protection Parameter Settings
P50 Agile P153
7-6
P153/EN M/B
Sr. No
Parameter
Defaults setting
Setting / Ranges
11. DST End Day Sunday
Sunday / Monday / Tuesday / Wednesday / Thursday /
Friday/ Saturday
Setting to specify the day of the week in which daylight saving time adjustment ends
12. DST End Month October
January / February / March / April / May / June / July /
August / September / October / November / December
Setting to specify the month in which daylight saving time adjustment ends
13. DST End Mins 60 Mins 0 to 1425 mins step 15mins.
Setting to specify the time of day in which daylight saving time adjustment ends. This is set relative to 00:00 hrs on the selected day when
time adjustment is to end
14. RP Time Zone Local UTC / Local
Setting for the rear port 1 interface to specify if time synchronization received will be local or universal time co-ordinated.
15.
SET Hours
10 *
0 to 23 Hrs step 1
Hour setting needed when relay is not connected to SCADA system
16. SET Minutes 35 * 0 to 59 Mins step 1
Minutes setting needed when relay is not connected to SCADA system
17. SET Seconds 54 * 0 to 59 Sec. step 1
Seconds setting needed when relay is not connected to SCADA system
18.
SET Date
28 *
1 to 31 Days step 1
Date setting needed when relay is not connected to SCADA system
19. SET Month 10 * 1 to 12 Months step 1
Month setting needed when relay is not connected to SCADA system
20. SET Year 14 * 0 to 99 Years step 1
Year setting needed when relay is not connected to SCADA system
Note: * The relay displays the current Date/Time set in the relay.
2.4 CONFIGURATION Settings
Sr. No Parameter Defaults setting Setting / Ranges
1. Password 0000 0000 to zzzz
This setting specifies to enter the set password
2. Restore Defaults No Operation
No Operation / All Settings / Setting Group 1 / Setting
Group 2
This setting restores the chosen setting groups to factory default values.
To restore the default values to any Group, set the ‘restore defaults’ cell to the relevant Group number. Alternatively it is possible to set
the ‘restore defaults’ cell to ‘all settings’ to restore the default values to all of the IED’s settings, not just the Group settings.
The default settings will be placed in Flash and will only be used by the IED after they have been confirmed by the user.
Note: Restoring defaults to all settings includes the rear communication port settings, which
may result in communication via the rear port being disrupted if the new (default)
settings do not match those of the master station
3. Active Settings Group 1 Group 1 / Group 2
This setting selects the active settings group.
4.
Copy From
Group 1
Group 1 / Group 2
This setting allows settings to be copied from a selected setting group.
