2.3.5 Measurement Menu
2.3.5.1 View Contents
MEASUREMENTS
This menu displays the measurements values of various parameters (i.e.
Phase current, measured and derived earth current, negative, positive
phase sequence current and I2/I1 ratio as per per phase / earth CT ratio,
TC (Trip Counter), BOC (Breaker Operation Counter), BOT (Breaker
Operating Time) and Th State (Thermal State).
IA = 0 A
IB = 0 A
This window shows primary value of current in phase A and B taking in
to account phase CT ratio.
IC = 0 A
IN1 = 0 A
This window shows primary value of current in phase C and measured
earth current taking in account phase CT and earth CT ratio respectively.
IN2 = 0 A
This window shows primary value of internally derived earth current.
ia = 0.00 A
ib = 0.00 A
This window shows secondary value of current in phase A and phase B.
ic = 0.00 A
in1 = 0.00 A
This window shows secondary value of current in phase C and
measured earth current.
in2= 0.00 A
i1 = 0.00 A
This window shows secondary value of internally derived earth current
and positive sequence current.
i2 = 0.00 A
I2/I1 =0.000
This window shows secondary value of negative sequence current and
ratio of negative and positive sequence current.
TC : 0
BOC : 0
This window shows Trip counter and Breaker operation counter.
