5 Configuration
P153/EN M/B
5-55
2.3.16.9.3
Edit Settings
(If I>1 Function selected for IEEE / US curve)
GROUP 1
Password protected window for “GROUP 1’’ settings:
SYSTEM CONFIG, OVERCURRENT, NEG SEQUENCE O/C, BROKEN
CONDUCTOR, EARTH FAULT 1, EARTH FAULT 2, THERMAL
OVERLOAD, COLD LOAD PICKUP, UNDERCURRENT and CB FAIL.
Note: Group 1 Setting will be seen only when it is enabled and set as
Active Group in Configuration setting.
COLD LOAD PKP
Password protected window for
Cold Load Pickup
i.e. tcold Time Delay,
tclp Time Delay, I>1 Status, I>2 Status, I>3 Status, IN1>1 Status, IN1>2
Status, IN1>3 Status, IN2>1 Status, IN2>2 Status and IN2>3 Status.
tcold Time Delay
7200 S
Editable setting
By using the (5) or (6) key, tcold Time Delay can be set. The setting
range is from 0 to 14400s in steps of 1s.
tclp Time Delay
7200 S
Editable setting
By using the (5) or (6) key, tclp Time Delay can be set. The setting
range is from 0 to 14400 in steps of 1.
I>1 Status
Enabled
Editable setting
By using the (5) or (6) key, I>1 Status is Enabled.
I>1 Current Set
1.50 A
Editable setting
By using the (5) or (6) key, I>1 Current Set can be set. The setting
range is from 0.05 to 4.00 In in steps of 0.01 In.
I>1 Time Dial
1.00
Editable setting
By using the (5) or (6) key, I>1 Time Dial can be set. The setting
range is from 0.01 to 100 in steps of 0.01
Note : The settings of I>2 Status, I>3 Status, IN1>1 Status, IN1>2 Status, IN1>3 Status, IN2>1 Status,
IN2>2 Status, IN2>3 Status can be set in similar manner as that of I>1 Status.
2.3.16.9.4
Edit Settings
(If I>1 Function if selected for DT)
GROUP 1
Password protected window for “GROUP 1’’ settings:
SYSTEM CONFIG, OVERCURRENT, NEG SEQUENCE O/C, BROKEN
CONDUCTOR, EARTH FAULT 1, EARTH FAULT 2, THERMAL
OVERLOAD, COLD LOAD PICKUP, UNDERCURRENT and CB FAIL.
Note: Group 1 Setting will be seen only when it is enabled in
Configuration setting.
