5 Configuration
P153/EN M/B
5-59
I<
1.00 A
By using the (5) or (6) key,
I<
can be set
.
The setting range is from
0.05 to 3.2 In in steps of 0.01In
IN<
1.00 A
By using the (5) or (6) key, IN< can be set. The setting range is from
0.05 to 3.2 In in steps of 0.01In
Remove I> Start
Disabled
Editable setting
By using the (5) or (6) key, Remove I> Start can be Enabled /
Disabled
Remove IN> Start
Disabled
Editable setting
By using the (5) or (6) key, Remove IN> Start can be Enabled /
Disabled
2.3.17 Group 2 Menu
2.3.17.1
Edit Settings
GROUP 2
Password protected window for
“GROUP 2’’
settings:
SYSTEM CONFIG, OVERCURRENT, NEG SEQUENCE O/C, BROKEN
CONDUCTOR, EARTH FAULT 1, EARTH FAULT 2, THERMAL
OVERLOAD, COLD LOAD PICKUP, UNDERCURRENT and CB FAIL.
Note: Group 2 Setting will be seen only when it is enabled in
Configuration setting.
SYSTEM CONFIG
Password protected window for System Configuration i.e. 2nd
Harmonic Disabled/Enabled, 2ndHarm Thresh and I>lift 2H.
OVERCURRENT
Password protected window for Overcurrent
i.e. I>1 Function, I>2
Function and I>3 Function. The functions can be set as Disabled / DT /
IDMT.
NEG SEQUENCE O/C
Password protected window for Negative Sequence O/C i.e. I2>1
Function, I2>2 Function and I2>3 Function. The functions can be set as
Disabled / DT / IDMT.
BROKEN CONDUCTOR
Password protected window for
Broken Conductor
i.e. BC Alarm
(Enable/Disabled), I2/I1 Setting - 1 and I2/I1 Time Dly – 1, BC Trip
(Enable/Disabled), I2/I1 Setting - 2 and I2/I1 Time Dly - 2.
