P50 Agile P153
5 Configuration
P153/EN M/B
5-30
2.3.12.2.2 LED Green Configuration
LED G (Green) can be assigned by selecting any function available in the submenus. There are in
all 2 numbers of programmable LEDs identified as L5 to L6.
2.3.12.2.3 LED Red Configuration
LED R (Red) can be assigned by selecting any function available in the submenus. There are in
all 2 numbers of programmable LEDs identified as L5 to L8.
2.3.12.2.4 AND Logic
AND Logic can be assigned by selecting any function available in the submenus. There are in all
4 numbers of AND Logic with identifier as A, B, C & D.
The functions assigned to Relay, LED G, LED R and AND Logic are listed in Chapter 8:
Monitoring and Control.
2.3.13 O/P Relay Configuration Menu
2.3.13.1 View/Edit Settings
O/P RELAY CONFIG
Password protected window for “O/P RELAY CONFIGURATION’’
settings: Contact HR/SR, O/P-1 Open Time, O/P-2 Open Time, O/P-3
Open Time and O/P-4 Open Time, LED G HR/SR, LED R HR/SR,
ANDEQ A Op Time, ANDEQ Rst Time, ANDEQ B Op Time, ANDEQ B
Rst Time, ANDEQ C Op Time, ANDEQ C Rst Time, ANDEQ D Op Time
and ANDEQ D Rst Time.
Contact HR/SR
0000
Editable setting
By using the (5) or (6) key, the desired Contact HR/SR can be set as
‘1’=HR / ’0’=SR.
O/P–1 Open Time
0.50 S
Editable setting
By using the (5) or (6) key, the desired O/P–1 Open Time can be set.
The setting range is from 0 to 1s in steps of 0.01s
O/P–2 Open Time
0.50 S
Editable setting
By using the (5) or (6) key, the desired O/P–2 Open Time can be set.
The setting range is from 0 to 1s in steps of 0.01s
O/P–3 Open Time
0.50 S
Editable setting
By using the (5) or (6) key, the desired O/P–3 Open Time can be set.
The setting range is from 0 to 1s in steps of 0.01s
O/P–4 Open Time
0.50 S
Editable setting
By using the (5) or (6) key, the desired O/P–4 Open Time can be set.
The setting range is from 0 to 1s in steps of 0.01s
