GE Agile P153 User Manual

P50 Agile P153
5 Configuration
P153/EN M/B
5-27
CB Fail
Disabled
Editable setting
By using the (5) or (6) key, CB Fail can be Enabled or Disabled.
Setting Values
Secondary
Editable setting
By using the (5) or (6) key, Setting Values can be set as Primary /
Secondary.
2.3.9 Transformer Ratios Menu
2.3.9.1 View/Edit Settings
TRANS. RATIOS
Password protected window for “TRANS. RATIOS settings :
Phase CT Primary, Phase CT Secondary, E/F CT Primary and E/F CT
Secondary.
Phase CT Primary
100 A
Editable setting
By using the (5) or (6) key, Phase CT Primary can be set. The
setting range is from 1A to 30000A step 1A.
Phase CT Sec’y
1 A
Editable setting
By using the (5) or (6) key, Phase CT Secondary can be set as 1A /
5A.
E/F CT Primary
100 A
Editable setting
By using the (5) or (6) key, E/F CT Primary can be set. The setting
range is from 1A to 30000A step 1A.
E/F CT Secondary
1 A
Editable setting
By using the (5) or (6) key, E/F CT Secondary can be set as 1A / 5A.
2.3.10 Record Control Menu
2.3.10.1 View/Edit Settings
RECORD CONTROL
Password protected window for “RECORD CONTROL’’ settings :
Clear Events (Yes/No), Clear Faults (Yes/No), Clear Dist Recs (Yes/No),
Clear Maint (Yes/No), Thermal Reset (Yes/No).
