P50 Agile P153
5 Configuration
P153/EN M/B
5-58
I<
1.00 A
By using the (
5
) or (
6
) key, I< can be set. The setting range is from
0.05 to 3.2 In in steps of 0.01 In
IN<
1.00 A
By using the (5) or (6) key,
IN<
can be set
.
The setting range is from
0.05 to 3.2 In in steps of 0.01 In
Remove I> Start
Disabled
Editable setting
By using the (5) or (6) key, Remove I> Start can be Enabled /
Disabled
Remove IN> Start
Disabled
Editable setting
By using the (5) or (6) key, Remove IN> Start can be Enabled /
Disabled
2.3.16.11.2 Edit Settings (If CB Fail Status is enabled)
GROUP 1
Password protected window for “GROUP 1’’ setting i.e. SYSTEM
CONFIG, OVERCURRENT, NEG SEQUENCE O/C, BROKEN
CONDUCTOR, EARTH FAULT 1, EARTH FAULT 2, THERMAL
OVERLOAD, COLD LOAD PICKUP, UNDERCURRENT and CB FAIL.
Note: Group 1 Setting will be seen only when it is enabled in
Configuration setting.
CB FAIL
Password protected window for CB FAIL i.e. CB Fail Status, CB Fail
Timer, CB Reset, I<, IN<, Remove I> Start and Remove IN> Start.
CB Fail Status
Enabled
Editable setting
By using the (5) or (6) key, CB Fail Status is Enabled.
CB Fail Timer
0.10 S
Editable setting
By using the (5) or (6) key, CB Fail Timer can be set. The setting
range is from 0 to 50s in steps of 0.01s.
CBF Reset
CB Open+ I<
By using the (5) or (6) key, CBF Reset can be set as CB Open + I<,
Prot Reset + I<, CB Open, I<
