P50 Agile P153
5 Configuration
P153/EN M/B
5-7
2.1 Changing the Settings
SYSTEM DATA
Step 1: Press the (4) key to move to the next option.
Language
English
Step 2: Press the (
6
) key to move to the next option till the relay
displays CB Open/Close setting
: : :
: : :
CB Open/Close
Open
Step 3:
Press the (6) key till the relay displays this option.
Press ‘EDIT’ key to edit the setting.
Password = 0001
[All editable settings are password protected. So when the ‘EDIT’ key is
pressed, it will display the password and the settable number/text will
start blinking].
Step 4: Enter the password by using the (5) or the (6) key. The
Password is four (4) digits alpha numeric.
Password = 0000
** Password OK **
Step 5: After editing the Password, press the ‘EDIT’ key, the Password
OK message is displayed and settable number/text will start blinking and
the relay will move to the next option.
Note: When the password is set, modification can be done in any
settings within 15 minutes. After the lapse of 15 minutes, the relay will
once again ask to re-enter the password.
CB Open/Close
Open
Step 6: By using the (
5
) or (
6
) key, the desired selection can be set
as shown in the display.
CB Open/Close
Close
Step 7:
After setting, press the ‘
EDIT
’ key, the text will stop blinking and
move to the next option.
Step 8: Press the (3) / (4) key, it will ask if you want to save the
settings and move to the next option.
(
3
) For Save
CLEAR For Cancel
Step 9: When the (3) key is pressed again, it will save the changes
and move to the next option.
SAVE Settings
This window will flash for a moment and the control will return to the
main menu.
SYSTEM DATA
