Chapter 1. General Installation Instructions
4 AquaTrans™ AT600 User’s Manual
1.4 Unpacking the AT600 system
Before removing the AT600 system from the crate, please inspect the flow meter. Before discarding any of
the packing materials, account for all components and documentation listed on the packing slip. The
discarding of an important item along with the packing materials is all too common. If anything is missing
or damaged, contact BHGE Customer Care immediately for assistance.
Please note that the AT600 system (see Figure 4 below) is available in a variety of configurations to meet your
needs, so the packing list will vary for each system. As an example, a typical packing list is:
1. One AT600 electronics enclosure
2. Two clamp-on fixtures
3. Two transducers (installed in one of the two clamp-on fixtures)
4. One transducer cable (installed on fixture with transducers)
5. Two clamp-on fixture mounting straps for each fixture
6. Two “U” bolts for pipe mounting of the AT600 electronics enclosure
7. One USB flash drive with user’s manual and calibration sheet
8. One inner hexagon spanner
9. Three M16 cable glands (installed on the AT600 electronics enclosure)
10. Two pieces of Solid Couplant
11. Quick installation guide
12. Calibration Sheet
13. Cabling tools
Figure 4: Typical AT600 Shipping Container
