Chapter 4. Initial Setup and Programming
4.3 Display Programming
The AT600 keypad has six keys (see “AT600 Keypad Operation” on page 32) and the following two LEDs:
• Green: The green LED is a system health indicator and it is On when the meter is operating without
error.
• Red: The red LED is a system status indicator and it is On whenever the meter is in error.
Note: When both LEDs are Off, the meter is either in configuration mode or no power is applied.
4.3.1 Changing the Display for One- or Two-Variable Screens
An outline of a typical one- or two-variable screen is shown below.
To change the number of decimal places in the displayed value:
From the display screen, press either the [] or [] keys until the value is
highlighted.
After the value is highlighted, press
[] to open the Display/Decimal
option.
Velocity
m/s
0.0
0.0
Velocity
m/s
Soundspeed
m/s
0.0
Total m^3
Forward 0.0
Reverse 0.0
Velocity
m/s
0.0
Measurement Type
Value
Error Code
Value Units
Velocity
m/s
0.0
m/s
Velocity
0.0
