4.7.4 Programming the Pipe Menu when Clamp-on selected
4.7.4.1 Setting the Pipe OD, ID, and Wall Thickness
IMPORTANT: Changing the Pipe ID (Inside Diameter) automatically changes the Wall Thickness. Similarly,
c
hanging the Wall Thickness automatically changes the Pipe ID.
Select
Pipe and press [√]. The following screen opens.
In the
Sensor Setup menu, select Pipe OD, Pipe ID or Wall Thickness and
press [√]. A screen similar to the following opens.
Press
[] again, and a screen similar to the following opens.
Note: The units shown are the units selected in the
Units Setting menu.
Use the [] or [] key to select a specific digit, then use the [] or [] key
to change that digit as required. After all digits are correct, press
[] to
save. Then, press [
] to return to the previous screen. Repeat these steps
to enter the
Pipe ID and Wall Thickness. Then, press [] to return to the
Pipe menu.
