6-32 CASE Revision C
2060290-201
After the Test — Post Test Review
The Modify... buttons allow you to edit or complete the data in the
respective areas.
Patient Information: The Patient Information window opens.
Test Information: The Test Information window opens.
Measurement Results: A window opens where you can edit the
measurement results. Edited measurement results are identified
with the * symbol. You can also choose whether or not to display the
system evaluation.
Note
After opening the edit window with Modify..., you can select a
check box to remove the Exercise Test Interpretation from the
Measurement Results window.
Interpretation: A window opens where you can generate the test
interpretation (“Test End Phase” on page 6-29).
J
Click to display the interpretation window where a detailed interpretation
of the test can be generated.
K Click to activate the online Help program.
L Click to return to the initial screen.
