Applying Electrodes
CM5, CC5, CH (CMH) Auxiliary Lead Electrode Placement
In addition to the standard electrodes, apply one electrode on the
sternum (A1), one in location V5R/C5R (A2) and one on the neck (A3).
Electrode Electrode Placement
A1 Mid-sternum at the second intercostal space.
A2 In the fifth intercostal space in the right, anterior axillary line (V5F/
C5R).
A3 On either side of the neck or anywhere above the shoulders.
