Revision C CASE 6-31
2060290-201
After the Test — Post Test Review
After the Test — Post Test Review
Test Summary
Overview
A Click a tab to display the corresponding window.
B Patient Information area.
C Test Information area.
D Measurement Results area: area for exercise measurements and
machine “Exercise Test Interpretation (XTI)”.
E Interpretation area: area for the physician’s interpretation.
F Click to display patient list for a new test.
G
Click to display a list with more tests of the current patient (local
database).
H
Click to display a list with more tests of the current patient (MUSE
database system).
I Click to display the print setup window.
